Horizontal single axis tracking support

Inquiry

PREV：C-type steel photovoltaic mounting system NEXT：Shed photovoltaic mounting system

Product introduction

The horizontal single-axis photovoltaic support system generally adopts the north-south axis, and the north-south direction of the rotation axis is parallel tothe ground. The support angle is adjusted according to the azimuth of the sun to provide consistent power output throughout the day, which can improve the power generation efficiency by 20%.

Physical Properties

Type		Photovoltaic stents
Material	Material	Carbon steel
	Surface finishing/treatment	Pre-galvanized 8um/ Electro zinc Plating（≥12um） Hot -dip galvanized（＞60um） Plastic-spayed（＞60um） Power coating
Dimension range customizable is available	Width	Customizable is available
	Side Rail Height
	Length
	Thickness/wire diameter
	Max. Working Load
Accessories/related products
Product Features		1. Strong ability to adapt to terrain 2. High tracking accuracy 3. High power generation efficiency
Color		Design wind pressure: 0.55KN/㎡ Design snow pressure: 0.5KN/㎡ Service life: 30 Years
Enviroment demmand
Application		Fish ponds or all kinds of terrain
